Shim

1 YQX25D-0100 Case assy,Transmission 3 YQX25-0004 Plate,Lock 4 YQX30-0101 Bolt 7 GB91-86-3.228 3.228 Cotter pin 3.228 8 YQX30AS-0510 Filter components 9 GB1235-76-282.4 O 282.4 O-ring 282.4 10 YQX30AS-0503 Paper pad 11 YQX30AS-0501 Oil filter seat 12 GB93-87-10 10 Washer 10 13 GB70-85-M1030 M1030 Screw M1030 14 JB/ZQ4446-86-R1/2 R1/2 Screw plug R1/2 15 Q20-03-18242 18242 Gasket 18242 16 JDS30-0046 Screw plug 17 YQX30A-0400 Fuel lid assy 18 YQX30A-0007 Pipe oil fill 19 JB/ZQ4446-86-R1/4 R1/4 Screw plug R1/4 20 GB1235-76-152.4 O 152.4 O-ring 152.4 21 YQX38-1000 Hydraulic clutch,Assy 22 GB276-94-6206 6206 Bearing 6206 23 YQX30-0015 Shaft,Idler 24 YQX30-0013 Gear,Idler 25 GB893.1-86-24 24 Circlips for holes 24 26 GB276-94-6207 6207 Bearing 6207 27 YQX30-0012 Output gear 28 YQX30-0014 Nut 29 YQX30-0016 Pad 30 GB297-94-30208 30208 Bearing 30208 31 YQX30-0001 Retainer,Oil seal 32 GB1235-76-803.1 O 803.1 O-ring 803.1 33 YQX30-0005 Seal,Oil 34 GB297-94-32208 32208 Bearing 32208 35 YQX30-0003 Collar 36 2t-2.5t, 20 7 See Fig.20 Item 7 Shaft,Output 36 3t-3.8t, 20 7 See Fig.20 Item 7 Shaft,Output 37 YQX30-0002 Shim 38 YQX30-0004 Plate,Bearing support 39 GB93-87-8 8 Washer 8 40 GB5783-86-M820 M820 Bolt M820 42 GB119-86-B1220 B1220 Pin,Parallel B1220 43 YQXL18H-0201 Case, Torque-converter 44 YQX30-0202 Cover 45 GB818-85-M612 M612 Screw M612 46 GB5783-86-M1030 M1030 Bolt M1030 48 GB5783-86-M1075 M1075 Bolt M1075 49 GB5783-86-M1055 M1055 Bolt M1055 50 YQX30-0010 Shim 51 YQX30-3000 Charging pump 52 Q20-03-8141.5 8141.5 Gasket 8141.5 53 GB5780-86-M845 M845 Bolt M845 54 GB5780-86-M840 M840 Bolt M840 55 XYQX18-6000 YJH265E-3 Torque-converter 55 XYQX18H-6000 YJH265E-2 Torque-converter 55 XYQX30-6000 YJH265G-3 Torque-converter 55 XYQX30H-6000 YJH265G-2 Torque-converter 56 GB1235-76-242.4 O 242.4 O-ring 242.4 57 YQX30B-0510 Filter components 58 YQX30D-0502 Paper pad, Oil filter seat 59 YQX30D-0501 Oil filter seat
